High Modulus Square Carbon Fiber Tube 1 1/2″ ID x 1 5/8″ OD

$515.00$682.50

Clear

Volume Discount

5-9 10-24 25+
7% 15% Call for Details
*Discount applied at checkout*

Add-On Services

Custom Cut Length

Total Number of Pieces

Please Select Quantity of Pieces

Additional Custom Cut Length

Please select the quantity of pieces at this length

Additional Custom Cut Length 2

Please select the quantity of pieces at this length

Additional Notes / Comments

SKU: SQ-1.500-1.622-HMTW Categories: , ,

Description

This 1 1/2″ x 1 5/8″ high mod square carbon fiber tubing is fabricated with multiple layers of high strength unidirectional carbon fiber prepreg and has a 3K 2×2 twill fabric on the exterior.   Our square carbon fiber tube is roll-wrapped and fabricated in-house at our US facility.

Designed For: Bending applications

Fiber Orientation: Mostly 0° plies (axial) with some 90° plies (hoop)

Additional information

Weight N/A
Dimensions 1.5 × 1.628 in
Type

High-Mod

Nominal ID (in)

1.500

Nominal OD (in)

1.622

Wall Thickness (in)

0.061

Exterior Material

Twill

Finish

Cello-Wrap (Glossy/Textured)

Nominal ID Range

1.000" – 1.999"

Nominal OD Range

1.000" – 1.999"

Wall Thickness Range

0.044" – 0.086"

Length (in)

72, 96

Internal Radius (in)

0.125

External Radius (in)

0.189 (Reference Only)
